The definition and manufacturing process of steel plate mesh
Steel plate mesh is a net-like product formed by punching and stretching metal plates through special machinery.This process creates a uniform arrangement of rhombic,hexagonal or circular mesh structures in the metal plate.According to the forming method,it can be divided into punched type and stretched type,among which the stretching process can effectively enhance the mechanical properties of the material.
The uses of steel mesh
It has characteristics such as high strength,lightweight,and good ventilation and light transmission,and is widely used in fields like architecture,industry,and transportation.Its core features include diverse material selection,rhombic mesh structure,and multiple surface treatment processes.
Features
Made by stretching,elegant and stylish,durable and sturdy.
Surface treatment
Galvanization,plastic coating,anodizing.
| Specifications of Expanded Metal |
|
Plate
thickness(mm)
|
Hole width SWD(mm) |
Hole length
LWD(mm)
|
Mesh Stand
width (mm)
|
Mesh
width(mm)
|
Mesh
length(mm)
|
Weight
(kg/m2)
|
| 0.5 |
10 |
25 |
0.5 |
0.6 |
2 |
0.73 |
| 2 |
18 |
50 |
2.1 |
2 |
4 |
3.69 |
| 5 |
50 |
100 |
5 |
1.4 |
2.6 |
12.39 |
| 8 |
50 |
100 |
8 |
2 |
2.1 |
28.26 |
Packaging
woven bag
